Window and facade test stand

Test rigs (included within the scope of the accredited test laboratory):

  • Indoor window and façade test rig
  • Outdoor façade test rig


Test methods

  • Air permeability tests
  • Static and dynamic driving rain tests
  • Resistance to wind loads, including deformation tests
  • Verification of impact resistance and fall protection
  • Simulation of wind and rain via a calibrated control unit (control of air blowers, water pumps and spray equipment)

Technical Data

Window and facade test stand indoor
Window and facade test stand outdoor
Maximum test specimen dimensions
4,5 m (B) x 5,5 m (H)
10,0 m (B) x 10,0 m (H)
Maximum pressure differences
10.000 Pa
10.000 Pa
Maximum water flow
340 l/min
 340 l/min
Relevant standards and guidelines

In addition, a wide variety of tests are possible in which leakage rates, pressure or suction loads as well as tightness in the case of pressing and non-pressing water are to be determined. Examples are cavity floors, suspended ceilings, skylights, clean rooms.

Your contact

Daniel Scheuerer, staatl. gepr. Bautechniker

+49 8723 20-2058
